ChamSys Ltd www.chamsys.co.uk
MagicQ User Manual 239 Version 1.4.9.0
26.9.3 Using MagicQ with Coolux Pandoras Box
MagicQ supports Coolux Pandoras Box V1-V4, each version having different heads. The personality files
can be found under the coolux folder. Each Coolux Pandoras Box exists out of a number of video layers, a
number of graphic layers and 1 or 2 camera’s, depending on the of the configuration of the Coolux
Pandoras Box.
26.9.3.1 Coolux Media Player
Three different personality files are required for Coolux Media Player differing in type. The Media Player
consists of video layers, graphic layers and an ouput (camera). The table below shows how to patch 2
Mediaplayers:
There are 2 types of Mediaplayer in v4.1:
• Mediaplayer STD: 2 video layers, 4 graphic layers and 1 camera layer that controls the output.
• Mediaplayer PRO: 4 video layers, 8 graphic layers and 1 camera layer that controls the output.
Mediaplayer STD Personality Universe Adress
1 coolux playerstdvidv4.hed 1 1
1 coolux playerstdvidv4.hed 1 23
1 coolux playerstdgraphv4.hed 1 45
1 coolux playerstdgraphv4.hed 1 66
1 coolux playerstdgraphv4.hed 1 87
1 coolux playerstdgraphv4.hed 1 108
1 coolux playerstdcamv4.hed 1 129
2 coolux playerstdvidv4.hed 1 146
2 coolux playerstdvidv4.hed 1 168
2 coolux playerstdgraphv4.hed 1 190
2 coolux playerstdgraphv4.hed 1 211
2 coolux playerstdgraphv4.hed 1 232
2 coolux playerstdgraphv4.hed 1 253
2 coolux playerstdcamv4.hed 1 274
Mediaplayer Pro Personality Universe Adress
1 coolux playerprovidv4.hed 1 1
1 coolux playerprovidv4.hed 1 23
1 coolux playerprovidv4.hed 1 45
1 coolux playerprovidv4.hed 1 67
1 coolux playerprographv4.hed 1 89
1 coolux playerprographv4.hed 1 110
1 coolux playerprographv4.hed 1 131
1 coolux playerprographv4.hed 1 152
1 coolux playerprographv4.hed 1 173
1 coolux playerprographv4.hed 1 194
1 coolux playerprographv4.hed 1 215
1 coolux playerprographv4.hed 1 236
1 coolux playeroutv4.hed 1 257
2 coolux playerprovidv4.hed 1 294
