DGS-1210 Metro Ethernet Managed Switch CLI Reference Guide
286
34
Q-IN-Q COMMANDS
The Link Aggregation commands in the Command Line Interface (CLI) are listed (along with the appropriate
parameters) in the following table.
Command
Parameter
enable qinq
disable qinq
show qinq {ports [<portlist> | inner_tpid]}
config qinq ports
[<portlist> | all] [role [nni | uni] | outer_tpid <hex 0x1 - 0xffff> | add_inner_tag <hex
0x1-0xffff> | missdrop [enable | disable]]
config qinq inner_tpid <hex 0x1-0xffff>
create vlan_translation
ports <portlist> [add | replace] cvid <vidlist> svid <vlanid 1-4094> {priority
<priority 0-7>}
show vlan_translation {cvid <vidlist>}
delete vlan_translation ports [<portlist> | all] {cvid [<vidlist> | all]}
Each command is listed in detail, as follows:
enable qinq
Purpose To enable the Q-in-Q mode.
Syntax
enable qinq
Description
The enable qinq command creates a used to enable the Q-in-Q
mode.
When Q-in-Q is enabled, all network port roles will be NNI port and
their outer TPID will be set to 88a8. All existing static VLANs will run
as SP-VLAN. All dynamically learned L2 address wil
l be cleared.
GVRP and STP need to be disabled manually.
If you need to run GVRP on the Switch, firstly enable GVRP
manually. The default setting of Q-in-Q is disabled.
Parameters None.
Restrictions Only administrator or operator-level users can issue this command.
Example usage:
To enable Q-in-Q:
DGS-1210-28MP/ME:5# enable qinq
Command: enable qinq
Success.
DGS-1210-28MP/ME:5#
