Alarms
Chapter 2: Troubleshooting Procedures
Page 2 - 30 Isolette® Infant Incubator (Model C2000) Service Manual
For an explanation of weighing scale alarms, refer to table 2-5 on page
2-30.
Table 2-5. Weighing Scale Alarms
For an explanation of system prompt messages, refer to table 2-6 on
page 2-30.
Table 2-6. System Prompt Messages
Oxygen Cell Differ-
ent
The alarm message appears, an alarm
sounds, and the Alarm indicators flash to
indicate that the oxygen cell readings dif-
fer by greater than 3%.
Go to RAP 2.43
on page 2-112.
Oxygen Solenoid
Fail
This message informs the user that the
oxygen solenoid has failed.
Go to RAP 2.43
on page 2-112.
Alarm Description Action
Too Much Weight The alarm message appears with an
audible alarm and flashing alarm indica-
tors to indicate that the weight on the
mattress is in excess of 15 lb (7 kg), or
when zeroing, this message appears if a
weight in excess of 2 lb (1 kg), or with
software version 2.05 or higher, 7.7 lb
(3.5 kg) is on the mattress.
Go to RAP 2.47
on page 2-116.
Scale Disconnected The alarm message appears if the cable
between the scale and the sensor mod-
ule is disconnected.
Go to RAP 2.47
on page 2-116.
Clear Mattress The alarm message appears if extrane-
ous objects are on the mattress.
Go to RAP 2.47
on page 2-116.
Prompt Message Description Action
Power-On Test in
Progress
This message indicates that the con-
troller is performing the power-up
test.
No action required.
21% Cal This message indicates that the oxy-
gen control system is performing the
21% calibration procedure.
No action required.
Alarm Description Action
