Dräger Isolette C2000 Service Manual

Alarms
Chapter 2: Troubleshooting Procedures
Isolette® Infant Incubator (Model C2000) Service Manual Page 2 - 31
2
For an explanation of Silence/Reset key functions, refer to table 2-7 on
page 2-32.
100% Cal This message indicates that the oxy-
gen control system is performing the
100% calibration procedure.
No action required.
Cal Pass This message indicates that the oxy-
gen control system is successfully
calibrated.
No action required.
Cal Fail This message indicates that the oxy-
gen control system has failed to cali-
brate.
Go to RAP 2.48 on
page 2-119.
Procedural Silence This message indicates that the 5-
minute Procedural Silence is active.
During this time, Low Skin/Air Tem-
perature alarms automatically
silence for 15 minutes, and the Low
Oxygen % alarm automatically
silences for 4 minutes.
No action required.
Not Installed This message informs the user that
the humidity or oxygen systems are
not activated or installed.
Install the humidity
system (refer to pro-
cedure 7.3 on page
7-15).
or
Install the oxygen
system (refer to pro-
cedure 7.2 on page
7-8).
Slide Out Sensor This message advises the user to
withdraw the sensor module from the
hood during 21% oxygen calibration.
Withdraw the sensor
module assembly
from the hood.
Slide In Sensor This message advises the user to
return the sensor module inside the
hood during 21% oxygen calibration.
Slide the sensor mod-
ule assembly into the
hood.
Zeroing Failed This message informs the user that
the weight is greater than 7.7 lb (3.5
kg) on the mattress during infant
ZERO.
Go to RAP 2.47 on
page 2-116.
Prompt Message Description Action
