Enterasys D-Series CLI Reference 15-1
15
RMON Configuration
ThischapterdescribesthecommandsusedtoconfigureRMONonaD‐Seriesswitch.
RMON Monitoring Group Functions
RMON(RemoteNetworkMonitoring)providescomprehensivenetworkfaultdiagnosis,
planning,andperformancetuninginformationandallowsforinteroperabilitybetweenSNMP
managementstationsandmonitoringagents.RMONextendstheSNMPMIBcapabilityby
definingadditionalMIBsthatgenerateamuchrichersetofdataaboutnetworkusage.
TheseMIB
“groups”eachgatherspecificsetsofdatatomeetcommonnetworkmonitoringrequirements.
Table 15‐39liststheRMONmonitoringgroupssupportedonD‐Seriesdevices,eachgroup’s
functionandtheelementsitmonitors,andtheassociatedconfigurationcommandsneeded.
For information about... Refer to page...
RMON Monitoring Group Functions 15-1
Statistics Group Commands 15-3
History Group Commands 15-6
Alarm Group Commands 15-9
Event Group Commands 15-13
Filter Group Commands 15-17
Packet Capture Commands 15-22
Table 15-39 RMON Monitoring Group Functions and Commands
RMON
Group
What It Does... What It Monitors... CLI Command(s)
Statistics Records statistics
measured by the RMON
probe for each monitored
interface on the device.
Packets dropped, packets
sent, bytes sent (octets),
broadcast and multicast
packets, CRC errors,
oversized and undersized
packets, fragments, jabbers,
and counters for packets.
“show rmon stats” on
page 15-3
“set rmon stats” on
page 15-4
“clear rmon stats” on
page 15-4
