GD32VF103 User Manual

1: Reset power control unit

BKPIRST

Backup interface reset

This bit is set and reset by software.

0: No reset

1: Reset backup interface

CAN1RST

CAN1 reset

This bit is set and reset by software.

0: No reset

1: Reset the CAN1

CAN0RST

CAN0 reset

This bit is set and reset by software.

0: No reset

1: Reset the CAN0

24:23

Reserved

Must be kept at reset value

I2C1RST

I2C1 reset

This bit is set and reset by software.

0: No reset

1: Reset the I2C1

I2C0RST

I2C0 reset

This bit is set and reset by software.

0: No reset

1: Reset the I2C0

UART4RST

UART4 reset

This bit is set and reset by software.

0: No reset

1: Reset the UART4

UART3RST

UART3 reset

This bit is set and reset by software.

0: No reset

1: Reset the UART3

USART2RST

USART2 reset

This bit is set and reset by software.

0: No reset

1: Reset the USART2

USART1RST

USART1 reset

This bit is set and reset by software.

0: No reset

1: Reset the USART1
