6
CONVERTER MODE SETTING SCREEN
6-94
9. [Port Settings] Menu
w Valid Timing ……………… Select the condition to send the audio signal.
(Default: Control Data Detection)
• Always-on Connection
Always sends the audio signal to the destination selected in [Input
Connection Port].
• When "IP Network" or "Emergency" is selected in [Input Connection Port],
this option cannot be selected.
• Voice Data Detection
When an audio signal is input, sends the audio signal to the destination
selected in [Input Connection Port].
• Control Data Detection
When the control signal is input, sends the audio signal to the destination
selected in [Input Connection Port].
e Transmission Cancel …… Select “Enable” to automatically cancel the call, when a call is received
through the [EXT1]/[EXT2] port. (Default: Disable)
r Power for the Microphone Select “Enable” to supply the voltage to the microphone connected to A3/A4
terminal (Audio input) microphone. (Default: Disable)
M EXT Voice Terminal (continued)
VE-PG3 (Rear view)
• See Section 8 for port details.
A1~A4A1~A4 B1~B4B1~B4 C1~C4C1~C4
A1~A4
A1~A4 B1~B4B1~B4 C1~C4C1~C4
A1~A4
A1~A4 B1~B4B1~B4 C1~C4C1~C4
A1~A4
A1~A4 B1~B4B1~B4 C1~C4C1~C4
[EXT1] port[EXT2] port
[Port Settings]–[EXT Input 1 (EXT1)/EXT Input 2 (EXT2)]
u
*Appears only when “Voice Data Detection” is selected in [Valid Timing].
*
