Icom VE-PG3 - Page 86

5
BRIDGE MODE SETTING SCREEN
5-24
5. [Router] Menu (continued)
M Connection Settings
PPPoE
Configure the WAN connection. (Up to 8 destinations can be registered.)
q Select Connection ……… Select the WAN connection.
(Up to 8 destinations can be registered.)
(Default: WAN01)
w Nickname ………………… Enter an ISP name of up to 31 characters
e Username ………………… Enter a login user name or account name.
r Password ………………… Enter a login password.
• The entered characters are displayed as an * (asterisk) or a • (dot).
t Reconnect Mode ………… Select the PPPoE connection method.
(Default: Always-on)
• Manual
The PPPoE line can be manually connected or disconnected, by clicking
<Connect> or <Disconnect>.
• The network is disconnected, when the VE-PG3 is booted.
• Always-on
The PPPoE line is always connected.
• You can manually connect or disconnect by clicking Connect or
Disconnect in the Connection Status item.
y IP Address …………………
Enter the WAN IP address, if specified by your ISP.
[Router]–[WAN]
