Signal Description
66 Datasheet
SUS_STAT# /
GPIO61
O
Suspend Status: This signal is asserted by the PCH to indicate
that the system will be entering a low power state soon. This can
be monitored by devices with memory that need to switch from
normal refresh to suspend refresh mode. It can also be used by
other peripherals as an indication that they should isolate their
outputs that may be going to powered-off planes.
Pin may also be used as GPIO61.
SUSCLK /GPIO62 O
Suspend Clock: This clock is an output of the RTC generator
circuit to use by other chips for refresh clock.
Pin may also be used as GPIO62.
SUSWARN# /
SUSPWRDNACK /
GPIO30
O
SUSWARN#: This pin asserts low when the PCH is planning to
enter the Deep S4/S5 power state and remove Suspend power
(using SLP_SUS#). The EC/motherboard controlling logic must
observe edges on this pin, preparing for SUS well power loss on a
falling edge and preparing for SUS well related activity (host/Intel
ME wakes and runtime events) on a rising edge. SUSACK# must be
driven to match SUSWARN# once the above preparation is
complete. SUSACK# should be asserted within a minimal amount
of time from SUSWARN# assertion as no wake events are
supported if SUSWARN# is asserted but SUSACK# is not asserted.
Platforms supporting Deep S4/S5, but not wishing to participate in
the handshake during wake and Deep S4/S5 entry may tie
SUSACK# to SUSWARN#.
This pin may be muxed with a GPIO for use in systems that do not
support Deep S4/S5. This pin is muxed with SUSPWRDNACK since
it is not needed in Deep S4/S5 supported platforms.
Reset type: RSMRST#
This signal is multiplexed with GPIO30 and SUSPWRDNACK.
SUSPWRDNACK /
SUSWARN# /
GPIO30
O
SUSPWRDNACK: Active high. Asserted by the PCH on behalf of
the Intel ME when it does not require the PCH Suspend well to be
powered.
Platforms are not expected to use this signal when the PCH’s Deep
S4/S5 feature is used.
This signal is multiplexed with GPIO30 and SUSWARN#.
SYS_PWROK I
System Power OK: This generic power good input to the PCH is
driven and utilized in a platform-specific manner. While PWROK
always indicates that the core wells of the PCH are stable,
SYS_PWROK is used to inform the PCH that power is stable to
some other system component(s) and the system is ready to start
the exit from reset.
SYS_RESET# I
System Reset: This pin forces an internal reset after being
debounced. The PCH will reset immediately if the SMBus is idle;
otherwise, it will wait up to 25 ms ±2 ms for the SMBus to idle
before forcing a reset on the system.
WAKE# I
PCI Express* Wake Event: Sideband wake signal on PCI Express
asserted by components requesting wake up.
Table 2-8. Power Management Interface Signals (Sheet 4 of 4)
Name Type Description
