Datasheet 673
EHCI Controller Registers (D29:F0, D26:F0)
16.2.2.7 ASYNCLISTADDR—Current Asynchronous List Address
Register
Offset: MEM_BASE + 38h–3Bh Attribute: R/W
Default Value: 00000000h Size: 32 bits
This 32-bit register contains the address of the next asynchronous queue head to be
executed. Since the PCH host controller operates in 64-bit mode (as indicated by a 1 in
64-bit Addressing Capability field in the HCCPARAMS register) (offset 08h, bit 0), then
the most significant 32 bits of every control data structure address comes from the
CTRLDSSEGMENT register (offset 08h). Bits [4:0] of this register cannot be modified by
system software and will always return 0s when read. The memory structure
referenced by this physical memory pointer is assumed to be 32-byte aligned.
16.2.2.8 CONFIGFLAG—Configure Flag Register
Offset: MEM_BASE + 60h–63h Attribute: R/W
Default Value: 00000000h Size: 32 bits
This register is in the suspend power well. It is only reset by hardware when the
suspend power is initially applied or in response to a host controller reset.
Bit Description
31:5
Link Pointer Low (LPL) — R/W. These bits correspond to memory address signals
[31:5], respectively. This field may only reference a Queue Head (QH).
4:0 Reserved.
Bit Description
31:1 Reserved.
0
Configure Flag (CF) — R/W. Host software sets this bit as the last action in its process
of configuring the Host controller. This bit controls the default port-routing control logic.
Bit values and side-effects are listed below. See Chapter 4 of the EHCI specification for
operation details.
0 = Compatibility debug only (default).
1 = Port routing control logic default-routes all ports to this host controller.
