Intel 6 SERIES CHIPSET - DATASHEET 01-2011 - Page 708

Integrated Intel
®
High Definition Audio Controller Registers
708 Datasheet
C4h–C7h ISD2LPIB ISD2 Link Position in Buffer 00000000h RO
C8h–CBh ISD2CBL ISD2 Cyclic Buffer Length 00000000h R/W
CCh–CDh ISD2LVI ISD2 Last Valid Index 0000h R/W
CEh–CFh ISD1FIFOW ISD1 FIFO Watermark 0004h R/W
D0h–D1h ISD2FIFOS ISD2 FIFO Size 0000h R/W
D2h–D3h ISD2FMT ISD2 Format 0000h R/W
D8h–DBh ISD2BDPL
ISD2 Buffer Descriptor List Pointer –
Lower Base Address
00000000h R/W, RO
DCh–DFh ISD2BDPU
ISD2 Buffer Description List Pointer –
Upper Base Address
00000000h R/W
E0h–E2h ISD3CTL
Input Stream Descriptor 3 (ISD3)
Control
040000h R/W, RO
E3h ISD3STS ISD3 Status 00h R/WC, RO
E4h–E7h ISD3LPIB ISD3 Link Position in Buffer 00000000h RO
E8h–EBh ISD3CBL ISD3 Cyclic Buffer Length 00000000h R/W
ECh–EDh ISD3LVI ISD3 Last Valid Index 0000h R/W
EEh–EFh ISD3FIFOW ISD3 FIFO Watermark 0004h R/W
F0h–F1h ISD3FIFOS ISD3 FIFO Size 0000h R/W
F2h–F3h ISD3FMT ISD3 Format 0000h R/W
F8h–FBh ISD3BDPL
ISD3 Buffer Descriptor List Pointer –
Lower Base Address
00000000h R/W, RO
FCh–FFh ISD3BDPU
ISD3 Buffer Description List Pointer –
Upper Base Address
00000000h R/W
100h–102h OSD0CTL
Output Stream Descriptor 0 (OSD0)
Control
040000h R/W, RO
103h OSD0STS OSD0 Status 00h R/WC, RO
104h–107h OSD0LPIB OSD0 Link Position in Buffer 00000000h RO
108h–10Bh OSD0CBL OSD0 Cyclic Buffer Length 00000000h R/W
10Ch–10Dh OSD0LVI OSD0 Last Valid Index 0000h R/W
10Eh–10Fh OSD0FIFOW OSD0 FIFO Watermark 0004h R/W
110h–111h OSD0FIFOS OSD0 FIFO Size 0000h R/W
112–113h OSD0FMT OSD0 Format 0000h R/W
118h–11Bh OSD0BDPL
OSD0 Buffer Descriptor List Pointer –
Lower Base Address
00000000h R/W, RO
11Ch–11Fh OSD0BDPU
OSD0 Buffer Description List Pointer –
Upper Base Address
00000000h R/W
120h–122h OSD1CTL
Output Stream Descriptor 1 (OSD1)
Control
040000h R/W, RO
123h OSD1STS OSD1 Status 00h R/WC, RO
Table 17-2. Intel
®
High Definition Audio Memory Mapped Configuration Registers
Address Map (Intel
®
High Definition Audio D27:F0) (Sheet 3 of 4)
HDBAR +
Offset
Mnemonic Register Name Default Access
