17.1.2.23 RIRBLBASE—RIRB Lower Base Address Register
(Intel
®
High Definition Audio Controller—D27:F0)
Memory Address:HDBAR + 50h Attribute: R/W, RO
Default Value: 00000000h Size: 32 bits
17.1.2.24 RIRBUBASE—RIRB Upper Base Address Register
(Intel
®
High Definition Audio Controller—D27:F0)
Memory Address:HDBAR + 54h Attribute: R/W
Default Value: 00000000h Size: 32 bits
17.1.2.25 RIRBWP—RIRB Write Pointer Register
(Intel
®
High Definition Audio Controller—D27:F0)
Memory Address:HDBAR + 58h Attribute: R/W, RO
Default Value: 0000h Size: 16 bits
Bit Description
31:7
CORB Lower Base Address — R/W. Lower address of the Response Input Ring Buffer,
allowing the RIRB base address to be assigned on any 128-B boundary. This register
field must not be written when the DMA engine is running or the DMA transfer may be
corrupted.
6:0
RIRB Lower Base Unimplemented Bits — RO. Hardwired to 0. This required the RIRB to
be allocated with 128-B granularity to allow for cache line fetch optimizations.
Bit Description
31:0
RIRB Upper Base Address — R/W. Upper 32 bits of the address of the Response
Input Ring Buffer. This register field must not be written when the DMA engine is
running or the DMA transfer may be corrupted.
Bit Description
15
RIRB Write Pointer Reset — R/W. Software writes a 1 to this bit to reset the RIRB
Write Pointer to 0. The RIRB DMA engine must be stopped prior to resetting the Write
Pointer or else DMA transfer may be corrupted.
This bit is always read as 0.
14:8 Reserved.
7:0
RIRB Write Pointer (RIRBWP) — RO. Indicates the last valid RIRB entry written by
the DMA controller. Software reads this field to determine how many responses it can
read from the RIRB. The value read indicates the RIRB Write Pointer offset in 2 DWord
RIRB entry units (since each RIRB entry is 2 DWords long). Supports up to 256 RIRB
entries (256 x 8 B = 2 KB). This register field may be written when the DMA engine is
running.
