Datasheet 761
PCI Express* Configuration Registers
19.1.4 PCISTS—PCI Status Register
(PCI Express*—D28:F0/F1/F2/F3/F4/F5/F6/F7/F6/F7)
Address Offset: 06h–07h Attribute: R/WC, RO
Default Value: 0010h Size: 16 bits
Bit Description
15
Detected Parity Error (DPE) — R/WC.
0 = No parity error detected.
1 = Set when the root port receives a command or data from the backbone with a
parity error. This is set even if PCIMD.PER (D28:F0/F1/F2/F3:04, bit 6) is not set.
14
Signaled System Error (SSE) — R/WC.
0 = No system error signaled.
1 = Set when the root port signals a system error to the internal SERR# logic.
13
Received Master Abort (RMA) — R/WC.
0 = Root port has not received a completion with unsupported request status from the
backbone.
1 = Set when the root port receives a completion with unsupported request status from
the backbone.
12
Received Target Abort (RTA) — R/WC.
0 = Root port has not received a completion with completer abort from the backbone.
1 = Set when the root port receives a completion with completer abort from the
backbone.
11
Signaled Target Abort (STA) — R/WC.
0 = No target abort received.
1 = Set whenever the root port forwards a target abort received from the downstream
device onto the backbone.
10:9
DEVSEL# Timing Status (DEV_STS) — Reserved per the PCI Express* Base
Specification.
8
Master Data Parity Error Detected (DPED) — R/WC.
0 = No data parity error received.
1 = Set when the root port receives a completion with a data parity error on the
backbone and PCIMD.PER (D28:F0/F1/F2/F3:04, bit 6) is set.
7
Fast Back to Back Capable (FB2BC) — Reserved per the PCI Express* Base
Specification.
6 Reserved
5 66 MHz Capable — Reserved per the PCI Express* Base Specification.
4 Capabilities List — RO. Hardwired to 1. Indicates the presence of a capabilities list.
3
Interrupt Status — RO. Indicates status of Hot-Plug and power management
interrupts on the root port that result in INTx# message generation.
0 = Interrupt is deasserted.
1 = Interrupt is asserted.
This bit is not set if MSI is enabled. If MSI is not enabled, this bit is set regardless of the
state of PCICMD.Interrupt Disable bit (D28:F0/F1/F2/F3/F4/F5/F6/F7/F6/F7:04h:bit
10).
2:0 Reserved
