PCI Express* Configuration Registers
760 Datasheet
19.1.3 PCICMD—PCI Command Register
(PCI Express*—D28:F0/F1/F2/F3/F4/F5/F6/F7/F6/F7)
Address Offset: 04h–05h Attribute: R/W, RO
Default Value: 0000h Size: 16 bits
Bit Description
15:11 Reserved
10
Interrupt Disable — R/W. This disables pin-based INTx# interrupts on enabled Hot-
Plug and power management events. This bit has no effect on MSI operation.
0 = Internal INTx# messages are generated if there is an interrupt for Hot-Plug or
power management and MSI is not enabled.
1 = Internal INTx# messages will not be generated.
This bit does not affect interrupt forwarding from devices connected to the root port.
Assert_INTx and Deassert_INTx messages will still be forwarded to the internal
interrupt controllers if this bit is set.
9 Fast Back to Back Enable (FBE) — Reserved per the PCI Express* Base Specification.
8
SERR# Enable (SEE) — R/W.
0 = Disable.
1 = Enables the root port to generate an SERR# message when PSTS.SSE is set.
7 Wait Cycle Control (WCC) — Reserved per the PCI Express Base Specification.
6
Parity Error Response (PER) — R/W.
0 = Disable.
1 = Indicates that the device is capable of reporting parity errors as a master on the
backbone.
5 VGA Palette Snoop (VPS) — Reserved per the PCI Express* Base Specification.
4
Postable Memory Write Enable (PMWE) — Reserved per the PCI Express* Base
Specification.
3 Special Cycle Enable (SCE) — Reserved per the PCI Express* Base Specification.
2
Bus Master Enable (BME) — R/W.
0 = Disable. Memory and I/O requests received at a Root Port must be handled as
Unsupported Requests.
1 = Enable. Allows the root port to forward Memory and I/O Read/Write cycles onto the
backbone from a PCI Express* device.
NOTE: This bit does not affect forwarding of completions in either upstream or
downstream direction nor controls forwarding of requests other than memory or
I/O
1
Memory Space Enable (MSE) — R/W.
0 = Disable. Memory cycles within the range specified by the memory base and limit
registers are master aborted on the backbone.
1 = Enable. Allows memory cycles within the range specified by the memory base and
limit registers can be forwarded to the PCI Express device.
0
I/O Space Enable (IOSE) — R/W. This bit controls access to the I/O space registers.
0 = Disable. I/O cycles within the range specified by the I/O base and limit registers are
master aborted on the backbone.
1 = Enable. Allows I/O cycles within the range specified by the I/O base and limit
registers can be forwarded to the PCI Express device.
