Signal Description
78 Datasheet
SDVO_CTRLDATA I/O Port B: HDMI Control Data. Shared with Port B SDVO
SDVO_INTP I SDVO_INTP: Serial Digital Video Input Interrupt
SDVO_INTN I SDVO_INTN: Serial Digital Video Input Interrupt Complement.
SDVO_TVCLKINP I
SDVO_TVCLKINP: Serial Digital Video TVOUT Synchronization
Clock.
SDVO_TVCLKINN I
SDVO_TVCLKINN: Serial Digital Video TVOUT Synchronization
Clock Complement.
SDVO_STALLP I SDVO_STALLP: Serial Digital Video Field Stall.
SDVO_STALLN I SDVO_STALLN: Serial Digital Video Field Stall Complement.
DDPC_[3:0]P O
Port C: Capable of HDMI / DVI / DP
HDMI / DVI Port C Data and Clock Lines
DDPC_[0]P: TMDSC_DATA2
DDPC_[1]P: TMDSC_DATA1
DDPC_[2]P: TMDSC_DATA0
DDPC_[3]P: TMDSC_CLK
DisplayPort Port C
DDPC_[0]P: Display Port Lane 0
DDPC_[1]P: Display Port Lane 1
DDPC_[2]P: Display Port Lane 2
DDPC_[3]P: Display Port Lane 3
DDPC_[3:0]N O
Port C: Capable of HDMI / DVI / DisplayPort
HDMI / DVI Port C Data and Clock Line Complements
DDPC_[0]N: TMDSC_DATA2B
DDPC_[1]N: TMDSC_DATA1B
DDPC_[2]N: TMDSC_DATA0B
DDPC_[3]N: TMDSC_CLKB
DisplayPort Port C Complements
DDPC_[0]N: Lane 0 complement
DDPC_[1]N: Lane 1 complement
DDPC_[2]N: Lane 2 complement
DDPC_[3]N: Lane 3 complement
DDPC_AUXP I/O Port C: Display Port Aux
DDPC_AUXN I/O Port C: Display Port Aux Complement
DDPC_HPD I Port C: TMDSC_HPD Hot Plug Detect
DDPC_CTRLCLK I/O HDMI Port C Control Clock
DDPC_CTRLDATA I/O HDMI Port C Control Data
Table 2-23. Digital Display Interface Signals (Sheet 2 of 3)
Name Type Description
