Intel® Management Engine Interface (MEI) Subsystem Registers (D22:F0)
876 Datasheet
23.1.21 MC—Message Signaled Interrupt Message Control Register
(MEI—D22:F0)
Address Offset: 8Eh–8Fh Attribute: R/W, RO
Default Value: 0080h Size: 16 bits
23.1.22 MA—Message Signaled Interrupt Message Address
Register
(MEI—D22:F0)
Address Offset: 90h–93h Attribute: R/W, RO
Default Value: 00000000h Size: 32 bits
23.1.23 MUA—Message Signaled Interrupt Upper Address Register
(MEI—D22:F0)
Address Offset: 94h–97h Attribute: R/W
Default Value: 00000000h Size: 32 bits
23.1.24 MD—Message Signaled Interrupt Message Data Register
(MEI—D22:F0)
Address Offset: 98h–99h Attribute: R/W
Default Value: 0000h Size: 16 bits
Bit Description
15:8 Reserved.
7
64 Bit Address Capable (C64) — RO. Specifies that function is capable of generating
64-bit messages.
6:1 Reserved
0
MSI Enable (MSIE) — R/W. If set, MSI is enabled and traditional interrupt pins are
not used to generate interrupts.
Bit Description
31:2
Address (ADDR) — R/W. Lower 32 bits of the system specified message address,
always DW aligned.
1:0 Reserved.
Bit Description
31:0
Upper Address (UADDR) — R/W. Upper 32 bits of the system specified message
address, always DW aligned.
Bit Description
15:0
Data (DATA) — R/W. This 16-bit field is programmed by system software if MSI is
enabled. Its content is driven during the data phase of the MSI memory write
transaction.
