Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 111
:MEASure:COUNter
[<source>] (see
page 495)
:MEASure:COUNter?
[<source>] (see
page 495)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= counter
frequency in Hertz in NR3 format
:MEASure:DEFine
DELay, <delay spec>
(see page 497)
:MEASure:DEFine?
DELay (see page 498)
<delay spec> ::=
<edge_spec1>,<edge_spec2>
edge_spec1 ::=
[<slope>]<occurrence>
edge_spec2 ::=
[<slope>]<occurrence>
<slope> ::= {+ | -}
<occurrence> ::= integer
:MEASure:DEFine
THResholds,
<threshold spec> (see
page 497)
:MEASure:DEFine?
THResholds (see
page 498)
<threshold spec> ::= {STANdard} |
{<threshold mode>,<upper>,
<middle>,<lower>}
<threshold mode> ::= {PERCent |
ABSolute}
:MEASure:DELay
[<source1>]
[,<source2>] (see
page 500)
:MEASure:DELay?
[<source1>]
[,<source2>] (see
page 500)
<source1,2> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::=
floating-point number delay time
in seconds in NR3 format
:MEASure:DUAL:CHARge
[<interval>]
[,<source1>][,<source
2>] (see page 502)
:MEASure:DUAL:CHARge?
[<interval>]
[,<source1>][,<source
2>] (see page 502)
<interval> ::= {CYCLe | DISPlay}
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= area in
Amp-hours, NR3 format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
