128 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:TRESponse
[<source>] (see
page 576)
:MEASure:TRESponse?
[<source>] (see
page 576)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= time in
seconds for the overshoot to
settle back into the band in NR3
format
:MEASure:VCESat
[<source>] (see
page 577)
:MEASure:VCESat?
[<source>] (see
page 577)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the VCE(sat)
value in NR3 format
Table 20 :MEASure Power Commands Summary (continued)
Command Query Options and Query Returns
Table 21 :MTESt Commands Summary
Command Query Options and Query Returns
:MTESt:ALL {{0 | OFF}
| {1 | ON}} (see
page 584)
:MTESt:ALL? (see
page 584)
{0 | 1}
:MTESt:AMASk:CREate
(see page 585)
n/a n/a
:MTESt:AMASk:SOURce
<source> (see
page 586)
:MTESt:AMASk:SOURce?
(see page 586)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:MTESt:AMASk:UNITs
<units> (see page 587)
:MTESt:AMASk:UNITs?
(see page 587)
<units> ::= {CURRent | DIVisions}
:MTESt:AMASk:XDELta
<value> (see page 588)
:MTESt:AMASk:XDELta?
(see page 588)
<value> ::= X delta value in NR3
format
