Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 131
:POD<n>:SIZE <value>
(see page 616)
:POD<n>:SIZE? (see
page 616)
<value> ::= {SMALl | MEDium |
LARGe}
:POD<n>:THReshold
<type>[suffix] (see
page 617)
:POD<n>:THReshold?
(see page 617)
<n> ::= 1-2 in NR1 format
<type> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format
[suffix] ::= {V | mV | uV }
Table 22 :POD<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 23 :POWer Commands Summary
Command Query Options and Query Returns
n/a :POWer:CLResponse?
(see page 626)
n/a
:POWer:CLResponse:APP
Ly (see page 627)
n/a n/a
n/a :POWer:CLResponse:DAT
A? (see page 628)
<binary_block> ::=
comma-separated data with
newlines at the end of each row
:POWer:CLResponse:FRE
Quency:MODE <mode>
(see page 629)
:POWer:CLResponse:FRE
Quency:MODE? (see
page 629)
<mode> ::= {SWEep | SINGle}
:POWer:CLResponse:FRE
Quency:STARt
<value>[suffix] (see
page 630)
:POWer:CLResponse:FRE
Quency:STARt? (see
page 630)
<value> ::= {20 | 100 | 1000 |
10000 | 100000 | 1000000 |
10000000}
[suffix] ::= {Hz | kHz| MHz}
:POWer:CLResponse:FRE
Quency:STOP
<value>[suffix] (see
page 631)
:POWer:CLResponse:FRE
Quency:STOP? (see
page 631)
<value> ::= {100 | 1000 | 10000 |
100000 | 1000000 | 10000000 |
20000000}
[suffix] ::= {Hz | kHz| MHz}
:POWer:CLResponse:PPD
ecade <pts> (see
page 632)
:POWer:CLResponse:PPD
ecade? (see page 632)
<pts> ::= {10 | 20 | 30 | 40 |
50}
:POWer:CLResponse:SOU
Rce:INPut <source>
(see page 633)
:POWer:CLResponse:SOU
Rce:INPut? (see
page 633)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:POWer:CLResponse:SOU
Rce:OUTPut <source>
(see page 634)
:POWer:CLResponse:SOU
Rce:OUTPut? (see
page 634)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
