1448 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
37 :WGEN<w> Commands
SINC Use these commands to set the sine cardinal signal
parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
100 mHz to
1MHz
20 mVpp to
9Vpp
±2.50 V
EXPRise Use these commands to set the exponential rise
signal parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
• ":WGEN<w>:VOLTage:HIGH" on page 1478
• ":WGEN<w>:VOLTage:LOW" on page 1479
100 mHz to
5MHz
20 mVpp to
10 Vpp
±5.00 V
EXPFall Use these commands to set the exponential fall
signal parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
• ":WGEN<w>:VOLTage:HIGH" on page 1478
• ":WGEN<w>:VOLTage:LOW" on page 1479
100 mHz to
5MHz
20 mVpp to
10 Vpp
±5.00 V
CARDiac Use these commands to set the cardiac signal
parameters:
• ":WGEN<w>:FREQuency" on page 1445
• ":WGEN<w>:PERiod" on page 1470
• ":WGEN<w>:VOLTage" on page 1477
• ":WGEN<w>:VOLTage:OFFSet" on
page 1480
100 mHz to
200 kHz
20 mVpp to
9Vpp
±2.50 V
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
2
(High-Z)
1
Offset
2
(High-Z)
1
