Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 147
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA
<string> (see
page 817)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA? (see
page 817)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:LENGth
<length> (see
page 818)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:LENGth?
(see page 818)
<start> ::= integer between 0 and
12, in NR1 format.
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:STARt
<start> (see page 819)
:SBUS<n>:CXPI:TRIGger
:PATTern:DATA:STARt?
(see page 819)
<start> ::= integer between 0 and
255, in NR1 format.
:SBUS<n>:CXPI:TRIGger
:PATTern:ID <string>
(see page 820)
:SBUS<n>:CXPI:TRIGger
:PATTern:ID? (see
page 820)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:CT
<string> (see
page 821)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:CT?
(see page 821)
<string> ::= "nn" where n ::= {0
| 1 | X}
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:DLC
<dlc> (see page 822)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:DLC?
(see page 822)
<dlc> ::= integer between -1
(don't care) and 15, in NR1
format, when trigger is in DATA
mode.
<dlc> ::= integer between -1
(don't care) and 255, in NR1
format, when trigger is in LDATa
mode.
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:NM
<string> (see
page 823)
:SBUS<n>:CXPI:TRIGger
:PATTern:INFO:NM?
(see page 823)
<string> ::= "nn" where n ::= {0
| 1 | X}
Table 29 :SBUS<n>:CXPI Commands Summary (continued)
Command Query Options and Query Returns
Table 30 :SBUS<n>:FLEXray Commands Summary
Command Query Options and Query Returns
:SBUS<n>:FLEXray:AUTo
setup (see page 826)
n/a n/a
:SBUS<n>:FLEXray:BAUD
rate <baudrate> (see
page 827)
:SBUS<n>:FLEXray:BAUD
rate? (see page 827)
<baudrate> ::= {2500000 | 5000000
| 10000000}
