Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 155
:SBUS<n>:SENT:SIGNal<
s>:DISPlay {{0 | OFF}
| {1 | ON}} (see
page 909)
:SBUS<n>:SENT:SIGNal<
s>:DISPlay? (see
page 909)
<s> ::= 1-6, in NR1 format.
{0 | 1}
:SBUS<n>:SENT:SIGNal<
s>:LENGth <length>
(see page 910)
:SBUS<n>:SENT:SIGNal<
s>:LENGth? (see
page 910)
<s> ::= 1-6, in NR1 format.
<length> ::= from 1-24, in NR1
format.
:SBUS<n>:SENT:SIGNal<
s>:MULTiplier
<multiplier> (see
page 912)
:SBUS<n>:SENT:SIGNal<
s>:MULTiplier? (see
page 912)
<s> ::= 1-6, in NR1 format.
<multiplier> ::= from 1-24, in
NR3 format.
:SBUS<n>:SENT:SIGNal<
s>:OFFSet <offset>
(see page 913)
:SBUS<n>:SENT:SIGNal<
s>:OFFSet? (see
page 913)
<s> ::= 1-6, in NR1 format.
<offset> ::= from 1-24, in NR3
format.
:SBUS<n>:SENT:SIGNal<
s>:ORDer <order> (see
page 914)
:SBUS<n>:SENT:SIGNal<
s>:ORDer? (see
page 914)
<s> ::= 1-6, in NR1 format.
<order> ::= {MSNFirst | LSNFirst}
:SBUS<n>:SENT:SIGNal<
s>:STARt <position>
(see page 916)
:SBUS<n>:SENT:SIGNal<
s>:STARt? (see
page 916)
<s> ::= 1-6, in NR1 format.
<position> ::= from 0-23, in NR1
format.
:SBUS<n>:SENT:SOURce
<source> (see
page 918)
:SBUS<n>:SENT:SOURce?
(see page 918)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SENT:TOLeran
ce <percent> (see
page 920)
:SBUS<n>:SENT:TOLeran
ce? (see page 920)
<percent> ::= from 3-30, in NR1
format.
:SBUS<n>:SENT:TRIGger
<mode> (see page 921)
:SBUS<n>:SENT:TRIGger
? (see page 921)
<mode> ::= {SFCMessage |
SSCMessage | FCData | SCMid |
SCData | FCCerror | SCCerror |
CRCerror | TOLerror | PPERror |
SSPerror}
:SBUS<n>:SENT:TRIGger
:FAST:DATA <string>
(see page 923)
:SBUS<n>:SENT:TRIGger
:FAST:DATA? (see
page 923)
<string> ::= "nnnn..." where n
::= {0 | 1 | X}
<string> ::= "0xn..." where n ::=
{0,..,9 | A,..,F | X | $}
Table 35 :SBUS<n>:SENT Commands Summary (continued)
Command Query Options and Query Returns
