Keysight Technologies InfiniiVision MSO-X 4154A

184 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:TRIGger:TV:POLarity
<polarity> (see
page 1218)
:TRIGger:TV:POLarity?
(see page 1218)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 1219)
:TRIGger:TV:SOURce?
(see page 1219)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:TV:STANdard
<standard> (see
page 1220)
:TRIGger:TV:STANdard?
(see page 1220)
<standard> ::= {NTSC | PAL | PALM
| SECam}
<standard> ::= {GENeric |
{P480L60HZ | P480} | {P720L60HZ |
P720} | {P1080L24HZ | P1080} |
P1080L25HZ | P1080L50HZ |
P1080L60HZ | {I1080L50HZ | I1080}
| I1080L60HZ} with extended video
triggering license
:TRIGger:TV:UDTV:ENUM
ber <count> (see
page 1221)
:TRIGger:TV:UDTV:ENUM
ber? (see page 1221)
<count> ::= edge number in NR1
format
:TRIGger:TV:UDTV:HSYN
c {{0 | OFF} | {1 |
ON}} (see page 1222)
:TRIGger:TV:UDTV:HSYN
c? (see page 1222)
{0 | 1}
:TRIGger:TV:UDTV:HTIM
e <time> (see
page 1223)
:TRIGger:TV:UDTV:HTIM
e? (see page 1223)
<time> ::= seconds in NR3 format
:TRIGger:TV:UDTV:PGTH
an <min_time> (see
page 1224)
:TRIGger:TV:UDTV:PGTH
an? (see page 1224)
<min_time> ::= seconds in NR3
format
Table 69 :TRIGger:TV Commands Summary (continued)
Command Query Options and Query Returns
Table 70 :TRIGger:ZONE Commands Summary
Command Query Options and Query Returns
:TRIGger:ZONE:SOURce
<source> (see
page 1226)
:TRIGger:ZONE:SOURce?
(see page 1226)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:ZONE:STATe
{{0 | OFF} | {1 |
ON}} (see page 1227)
:TRIGger:ZONE:STATe?
(see page 1227)
{0 | 1}
:TRIGger:ZONE<n>:MODE
<mode> (see page 1228)
:TRIGger:ZONE<n>:MODE
? (see page 1228)
<mode> ::= {INTersect |
NOTintersect}
<n> ::= 1-2 in NR1 format
