Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 187
:WAVeform:SOURce
<source> (see
page 1255)
:WAVeform:SOURce?
(see page 1255)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> | SBUS} for
DSO models
<source> ::= {CHANnel<n> | POD{1
| 2} | BUS{1 | 2} | FUNCtion<m> |
MATH<m> | SBUS} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
:WAVeform:SOURce:SUBS
ource <subsource>
(see page 1259)
:WAVeform:SOURce:SUBS
ource? (see page 1259)
<subsource> ::= {{SUB0 | RX |
MOSI} | {SUB1 | TX | MISO}}
n/a :WAVeform:TYPE? (see
page 1260)
<return_mode> ::= {NORM | PEAK |
AVER | HRES}
:WAVeform:UNSigned
{{0 | OFF} | {1 |
ON}} (see page 1261)
:WAVeform:UNSigned?
(see page 1261)
{0 | 1}
:WAVeform:VIEW <view>
(see page 1262)
:WAVeform:VIEW? (see
page 1262)
<view> ::= {MAIN}
n/a :WAVeform:XINCrement?
(see page 1263)
<return_value> ::= x-increment
in the current preamble in NR3
format
n/a :WAVeform:XORigin?
(see page 1264)
<return_value> ::= x-origin
value in the current preamble in
NR3 format
n/a :WAVeform:XREFerence?
(see page 1265)
<return_value> ::= 0
(x-reference value in the current
preamble in NR1 format)
n/a :WAVeform:YINCrement?
(see page 1266)
<return_value> ::= y-increment
value in the current preamble in
NR3 format
n/a :WAVeform:YORigin?
(see page 1267)
<return_value> ::= y-origin in
the current preamble in NR3
format
n/a :WAVeform:YREFerence?
(see page 1268)
<return_value> ::= y-reference
value in the current preamble in
NR1 format
Table 71 :WAVeform Commands Summary (continued)
Command Query Options and Query Returns
