Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 189
:WGEN<w>:FUNCtion
<signal> (see
page 1282)
:WGEN<w>:FUNCtion?
(see page 1285)
<signal> ::= {SINusoid | SQUare |
RAMP | PULSe | NOISe | DC | SINC
| EXPRise | EXPFall | CARDiac |
GAUSsian | ARBitrary}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:PUL
Se:WIDTh <width> (see
page 1286)
:WGEN<w>:FUNCtion:PUL
Se:WIDTh? (see
page 1286)
<width> ::= pulse width in
seconds in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:RAM
P:SYMMetry <percent>
(see page 1287)
:WGEN<w>:FUNCtion:RAM
P:SYMMetry? (see
page 1287)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:FUNCtion:SQU
are:DCYCle <percent>
(see page 1288)
:WGEN<w>:FUNCtion:SQU
are:DCYCle? (see
page 1288)
<percent> ::= duty cycle
percentage from 20% to 80% in NR1
format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:MODulation:A
M:DEPTh <percent>
(see page 1289)
:WGEN<w>:MODulation:A
M:DEPTh? (see
page 1289)
<percent> ::= AM depth percentage
from 0% to 100% in NR1 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:A
M:FREQuency
<frequency> (see
page 1290)
:WGEN<w>:MODulation:A
M:FREQuency? (see
page 1290)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
M:DEViation
<frequency> (see
page 1291)
:WGEN<w>:MODulation:F
M:DEViation? (see
page 1291)
<frequency> ::= frequency
deviation in Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
M:FREQuency
<frequency> (see
page 1292)
:WGEN<w>:MODulation:F
M:FREQuency? (see
page 1292)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
SKey:FREQuency
<percent> (see
page 1293)
:WGEN<w>:MODulation:F
SKey:FREQuency? (see
page 1293)
<frequency> ::= hop frequency in
Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
SKey:RATE <rate> (see
page 1294)
:WGEN<w>:MODulation:F
SKey:RATE? (see
page 1294)
<rate> ::= FSK modulation rate in
Hz in NR3 format
<w> ::= 1 in NR1 format
:WGEN<w>:MODulation:F
UNCtion <shape> (see
page 1295)
:WGEN<w>:MODulation:F
UNCtion? (see
page 1295)
<shape> ::= {SINusoid | SQUare|
RAMP}
<w> ::= 1 in NR1 format
Table 72 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
