Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 191
:WGEN<w>:TRACk:FREQue
ncy {{0 | OFF} | {1 |
ON}} (see page 1311)
:WGEN<w>:TRACk:FREQue
ncy? (see page 1311)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk:PHASe
<phase> (see
page 1312)
:WGEN<w>:TRACk:PHASe?
(see page 1312)
<w> ::= 1 or 2 in NR1 format
<phase> ::= -360 to +360 in NR1
format
:WGEN<w>:VOLTage
<amplitude> (see
page 1313)
:WGEN<w>:VOLTage?
(see page 1313)
<amplitude> ::= amplitude in
volts in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:HIGH
<high> (see page 1314)
:WGEN<w>:VOLTage:HIGH
? (see page 1314)
<high> ::= high-level voltage in
volts, in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:LOW
<low> (see page 1315)
:WGEN<w>:VOLTage:LOW?
(see page 1315)
<low> ::= low-level voltage in
volts, in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:OFFS
et <offset> (see
page 1316)
:WGEN<w>:VOLTage:OFFS
et? (see page 1316)
<offset> ::= offset in volts in
NR3 format
<w> ::= 1 or 2 in NR1 format
Table 72 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
Table 73 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 1319)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 1320)
:WMEMory<r>:DISPlay?
(see page 1320)
<r> ::= 1 to (# ref waveforms) in
NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 1321)
:WMEMory<r>:LABel?
(see page 1321)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
