Keysight Technologies InfiniiVision MSO-X 4154A

558 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
23 :MEASure Power Commands
:MEASure:REAL
[<source>] (see
page 574)
:MEASure:REAL?
[<source>] (see
page 574)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<return_value> ::= the real power
value in NR3 format
:MEASure:RIPPle
[<source>] (see
page 575)
:MEASure:RIPPle?
[<source>] (see
page 575)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the output
ripple value in NR3 format
:MEASure:TRESponse
[<source>] (see
page 576)
:MEASure:TRESponse?
[<source>] (see
page 576)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= time in
seconds for the overshoot to
settle back into the band in NR3
format
:MEASure:VCESat
[<source>] (see
page 577)
:MEASure:VCESat?
[<source>] (see
page 577)
<source> ::= {CHANnel<n>|
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the VCE(sat)
value in NR3 format
Table 106 :MEASure Power Commands Summary (continued)
Command Query Options and Query Returns
