56 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
:WGEN<w>:OUTPut:POLarity
(see page 1304)
Lets you invert the waveform generator output.
:WGEN<w>:MODulation:AM:DE
PTh (see page 1289)
Specifies the amount of amplitude modulation.
:WGEN<w>:MODulation:AM:FR
EQuency (see page 1290)
Specifies the frequency of the modulating signal.
:WGEN<w>:MODulation:FM:DE
Viation (see page 1291)
Specifies the frequency deviation from the original carrier signal
frequency.
:WGEN<w>:MODulation:FM:FR
EQuency (see page 1292)
Specifies the frequency of the modulating signal.
:WGEN<w>:MODulation:FSKey:
FREQuency (see page 1293)
Specifies the "hop frequency".
:WGEN<w>:MODulation:FSKey:
RATE (see page 1294)
Specifies the rate at which the output frequency "shifts".
:WGEN<w>:MODulation:FUNCt
ion (see page 1295)
Specifies the shape of the modulating signal.
:WGEN<w>:MODulation:FUNCt
ion:RAMP:SYMMetry (see
page 1296)
Specifies the amount of time per cycle that the ramp waveform is
rising.
:WGEN<w>:MODulation:STATe
(see page 1298)
Enables or disables modulated waveform generator output.
:WGEN<w>:MODulation:TYPE
(see page 1299)
Selects the modulation type: Amplitude Modulation (AM),
Frequency Modulation (FM), or Frequency-Shift Keying
Modulation (FSK).
:WGEN<w>:TRACk (see
page 1308)
Causes frequency, amplitude, offset, and duty cycle adjustments
to this waveform generator output signal to be tracked by the
other waveform generator output.
:WGEN<w>:TRACk:AMPLitude
(see page 1309)
Causes amplitude and offset adjustments to this waveform
generator output signal to be tracked by the other waveform
generator output.
:WGEN<w>:TRACk:CSIGnal
(see page 1310)
Copies the signal settings from one waveform generator to the
other.
:WGEN<w>:TRACk:FREQuency
(see page 1311)
Causes frequency adjustments to this waveform generator output
signal to be tracked by the other waveform generator output.
Command Description
