The system monitor
Introduction
You can open the system monitor to get an overview of the current status of the printing system.
When you click on the [System] tab in the lower left corner of the screen, the system monitor
pops up.
The system state (for example: [Printing:]) is displayed in the upper right corner of the system
monitor section of the Océ Express WebTools.
Overview of the system states
State Icon Description
[User intervention re-
quired]
The user is requested to go to the printer and follow the
instructions displayed on the operator panel.
[System memory is full] Status message when printer does not print because the
system memory is full.
[Sleeping...] Energy saving state: State when not all functionality is
available due to printer sleeping.
[Ready to print] State when there is no active job and no waiting job.
When a job arrives, no user intervention is needed to
start printing.
[Printing:] <job-name> State when a print job is active.
[Processing:] <job-name> The system is processing the job data.
[Receiving:] <job-name> The system is receiving the job data.
'Printer paused' State of the printer that has been set to 'Pause' on the
operator panel.
'E-shredding ready' Ready for E-shredding.
'Media indication' Roll media and roll width indication for roll 1 ... 6 (if
available) and cut sheet tray 1 and 2 (if available) .
[The system is not connec-
ted to Océ Remote Service]
The system is not connected to Océ Online services. The
tooltip contains detailed information on why the system
is not connected.
[The system is trying to
connect to Océ Remote
Service]
The system tries to make a connection with Océ Online
services ([Remote Assistance] option).
[The system is connected
to Océ Remote Service]
The system is connected to Océ Online services ([Re-
mote Assistance] option).
The media status:
The system monitor
Chapter 3 - Define your workflow with Océ Express WebTools
53
