Remove an empty tape roll
Introduction
If the tape roll is empty while the printer is in stand-by, one of these messages will appear on the
display
• If the tape roll is empty while the printer is in stand-by, one of these messages will appear on
the display:
• “Reinforcement unit empty” (if the printer was running when the roll ran out of tape).
If a tape roll is empty while the printer is running, this message will be accompanied by a picture
of the printer with the side door of the reinforcement unit blinking.
Procedure
1.
Open the side door of the reinforcement unit; see the illustration below.
[171] Opening the side door of the reinforcement unit
2.
Turn the two guide plates away from the pin roller and lock the two guide plates into their open
position.
[172] Opening the guide plates
3.
Remove the trailing strip of the old tape.
Remove an empty tape roll
Chapter 8 - Maintain and troubleshoot the Océ PlotWave 750 system
347
