Maximum folding length
Introduction
There are maximum values for different kinds of media. The table below shows the maximum
values for three types of media and the possible folding methods.
Maximum folding settings for long prints
Paper density (g/m
2
)
-->
60 75 110
Fold methods
First fold output
1 fold (mm / inch)
1220 / 48 6000 / 236 2500 / 98
Stacker 2nd fold
2 folds (mm / inch)
1220 / 48 2500 / 98 1220 / 48
Stacker 2nd fold
3 folds (mm / inch)
1220 / 48 2000 / 79 not possible
Belt 2nd fold
2 folds (mm / inch)
1220 / 48 1220 / 48 1220 / 48
Folding settings 75 grams
Output selection Output length Delivery
“Stacker” or
“Belt”
< 2.5 m Delivered on stacker or belt
“Stacker” or
“Belt”
2.5 m - 6 m First fold only, delivered in first fold delivery
“Stacker” or
“Belt”
> 6 m length known at start Unfolded, delivered in
IRT
“Stacker” or
“Belt”
> 6 m length not known at start Possible paper jam
“First fold only” < 6 m Delivered in first fold delivery
“First fold only” > 6 m length known at start Unfolded, delivered in
IRT
“First fold only” > 6 m length not known at start Possible paper jam
Folding settings 110 grams
Output selection
Output length Delivery
“Stacker” or
“Belt”
< 1.22 m (3 folds) Delivered in first fold delivery
“Stacker” or
“Belt”
< 1.22 m (2 folds) Delivered on stacker or belt
4
Maximum folding length
Chapter 7 - The finishing options
289
