Media
Load rolls of media
Introduction
When a roll is empty during a print job, a ‘Roll empty’ indication is displayed on the printer
operator panel and on the status bar of Océ Express WebTools. You then have to load a new roll
of media.
If you load new print media, you must tell the system the size of the material and the type of print
material (paper, transparent or polyester).
See
Preferred Océ media types and sizes
on page 365 for an overview of all materials that can be
used on the Océ PlotWave 750 printer.
When you load the media, you can place one roll at a time conveniently on top of the printer. Two
protruding roll retainers prevent the roll from dropping off the printer.
[118] Roll retainer
Procedure
1.
Open the appropriate roll drawer.
NOTE
Do not open more than one roll drawer at a time to prevent overbalance of the printer.
Media
Chapter 8 - Maintain and troubleshoot the Océ PlotWave 750 system
303
