DMTA-10045-01EN, Rev. E, August 2016
Control Functions
75
Changing Parameters in the PC (RF) Main Menu
The following information is applicable when the BondMaster 600 mode is set to PC
(RF) and the MAIN menu key ( ) has been pressed.
FREQ (frequency)
The FREQ (frequency) setting determines the frequency of the tone burst. This is
adjustable from 1 kHz to 50 kHz.
To change the FREQ setting, press the A key, and then rotate the knob to the
desired frequency.
Press the Enter key ( ) once, while the FREQ parameter is highlighted, to enable
the fine knob function, which decreases the frequency selection increments from 1.0
(coarse) to 0.1 (fine) increments. By default, the knob adjustment is set to coarse
increments, and FREQ is underlined when the coarse knob function is enabled. To
turn the coarse knob function back on, press one more time.
RF GAIN
The RF GAIN, or vertical gain, setting controls the gain of the tone burst signal.
This is adjustable from 0.0 dB to 70.0 dB.
The RF GAIN is the master gain setting, and it should be always be adjusted first
when a gain change is desired.
To change the RF GAIN setting, press the B key, and then rotate the knob to the
desired gain value.
WIDTH
The WIDTH setting controls the amount of time displayed after the beginning of
the tone burst that is displayed on the Y (amplitude) versus T (time display).
To change the WIDTH setting, press the C key, and then rotate the knob to the
desired width value.
