Example of processing
Example 1) Creating a new CIP message. (Data other than character string data is
written in 2 bytes)
[S1]... DT10 [S2]... H0002 [D]...DT100
S1: Data to be added S2: Format of the data to be
added
D: CIP message storage destination
Value Value Value
DT0 00H 05H S2 0002H DT100 0000H
Data
length
DT1 42H (B) 41H (A) DT101 34H 12H
DT2 44H (D) 43H (C)
DT3 00H 45H (E)
Operation result
S1: Data to be added D: CIP message storage destination
Value
Move data equivalent to 2 bytes
Value
DT0 00H 05H DT100 0002H
Data
length
DT1 42H (B) 41H (A) DT101 0005H
DT2 44H (D) 43H (C)
DT3 00H 45H (E)
17.33 CIPMSET [CIP Message Data Setting (Merging)]
17-164 WUME-FP7CPUPGR-12
