Example 2) When performing the output refresh for the send buffer of the
connection number 5 of the node number 2 (Abnormal end)
[S1]... U2 [S2]... U5 [D]... DT100
● EtherNet/IP configuration setting
Setting item Settings
Node number 2
Connection 5
Output Information (O>T)
Device Allocation
LD101 to LD102
LD104 to LD107
Value Send buffer Value Value
LD100 0 DT10 1
LD101 2233h 1
LD102 4455h
x
2 AABBh *
LD103
x
3 CCDDh *
LD104 8899h 4
LD105 AABBh
x
5 AABBh *
LD106 CCDDh
x
6 CCDDh *
LD107 EEFFh
x
7 EEFFh *
LD108
x
8 1122h
*
(Note 1) Send buffers to which devices are allocated
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set when the unit specified by UNITSEL is not the built-in ET-LAN.
To be set when the EtherNet/IP function is set to Not Use in the Ethernet unit configuration.
To be set in case of out-of-range values in indirect access (index modification).
Set when a value outside the range is specified for the parameter.
To be set when the I/O map, node, or connection that is specified by [S1] or [S2] does not
exist.
Use this instruction only for the connections in which the refresh method of the EtherNet/IP
setting is set to Instruction. An operation error occurs when the connection that other refresh
method other than that has been specified is specified.
To be set when the connection for which the amount of output data is 0 is specified.
To be set when the connection for which the number of refreshed data is 0 is specified.
17.38 EIP_OT (EtherNet/IP Output Refresh)
17-194 WUME-FP7CPUPGR-12
