Device
No.
Name Description
Device No. Error alarm relay
SD75 No.15
SD76 No.16
SD77 No.17
SD78 No.18
SD79 No.19
SD80
For
error
alarm
relay
Calendar timer
(year)
Saves time when the error alarm relay saved in SD61 turned on.
SD81
Calendar timer
(month)
SD82
Calendar timer
(day)
SD83
Calendar timer
(hours)
SD84
Calendar timer
(minutes)
SD85
Calendar timer
(seconds)
SD86
-SD89
(Not used)
SD90
FP7 MW Unit error
annunciation register 1st
unit
When an error occurs in the FP7 MW Unit, the error code is stored in
the high byte and the unit number is stored in the low byte.
bit no.
15 08 7
Error code
Unit No.
SD91
FP7 MW Unit error
annunciation register 2nd
unit
SD92
FP7 MW Unit error
annunciation register 3rd
unit
SD93
FP7 MW Unit error
annunciation register 4th
unit
SD94
FP7 MW Unit error
annunciation register 5th
unit
SD95
FP7 MW Unit error
annunciation register 6th
unit
SD96
-SD99
(Not used)
SD100 - SD115 and SD120 - SD135 (For logging trace control)
Device
No.
Name Description
SD100 Buffer free space for LOG0
Stores free space of buffer memory during logging.
Unit: kB
20.2 List of System Data Registers
