Device
No.
Name Description
SD101 Buffer free space for LOG1
SD102 Buffer free space for LOG2
SD103 Buffer free space for LOG3
SD104 Buffer free space for LOG4
SD105 Buffer free space for LOG5
SD106 Buffer free space for LOG6
SD107 Buffer free space for LOG7
SD108 Buffer free space for LOG8
SD109 Buffer free space for LOG9
SD110 Buffer free space for LOG10
SD111 Buffer free space for LOG11
SD112 Buffer free space for LOG12
SD113 Buffer free space for LOG13
SD114 Buffer free space for LOG14
SD115 Buffer free space for LOG15
SD120 Buffer overflow counter for LOG0
● Saves the number of times buffer overflow flags (e.g.
SR104 for LOG0) turn on.
● For checking the number of times logging data is lost
during the buffer overflow, register the buffer overflow
counter as logging data.
SD121 Buffer overflow counter for LOG1
SD122 Buffer overflow counter for LOG2
SD123 Buffer overflow counter for LOG3
SD124 Buffer overflow counter for LOG4
SD125 Buffer overflow counter for LOG5
SD126 Buffer overflow counter for LOG6
SD127 Buffer overflow counter for LOG7
SD128 Buffer overflow counter for LOG8
SD129 Buffer overflow counter for LOG9
SD130 Buffer overflow counter for LOG10
SD131 Buffer overflow counter for LOG11
SD132 Buffer overflow counter for LOG12
SD133 Buffer overflow counter for LOG13
SD134 Buffer overflow counter for LOG14
SD135 Buffer overflow counter for LOG15
SD220-SD254
Device
No.
Name Description
SD220
Operation history No.0 Number of
records
Stores the number of accumulated operation history records.
20.2 List of System Data Registers
20-14 WUME-FP7CPUPGR-12
