Panasonic FP7 Series Command Reference Manual

X101
Y110
X102
Y111
X103
Process 1
R1
X101
R1
SSTP
Y110
NSTL
R2
X102
NSTL
(Program)
R2
SSTP
Y111
STPE
Process 2
X103
CSTP
(Program)
Starts the process
(process 1).
R2
Clears the
process
(process 2).
Starts the next
process
(process 2).
Process 1
Process 2
■
Example (2) Selective branch control of processes
● This program selects and switches to the next process according to the actions and results
of a particular process. Each process loops until its work is completed.
3.32 SSTP (Start Step) / NSTL (Next Step) / CSTP (Clear Step) / STPE (Step
End)
WUME-FP7CPUPGR-12 3-99
