Panasonic FP7 Series Command Reference Manual

■
Specification of control data [N]
・・・・ 0000 ・・・・ 0000
15 1211 8 7 4 3 0
Ignore the bits indicated with '・'.
n:
nH (Specify the result
output start bit)
Bit 0: H0
｜
Bit 15: HF
nL (Specify the conversion-
enabled bit length)
2
1
bits: H1
｜
2
8
bits: H8
■
Conversion example
Data to be converted (16
bits)
Encoding result Data to be converted (16
bits)
Encoding result
0000 0000 0000 0001 0000 0000 0001 0000 0000 1000
0000 0000 0000 0010 0001 0000 0010 0000 0000 1001
0000 0000 0000 0100 0010 0000 0100 0000 0000 1010
0000 0000 0000 1000 0011 0000 1000 0000 0000 1011
0000 0000 0001 0000 0100 0001 0000 0000 0000 1100
0000 0000 0010 0000 0101 0010 0000 0000 0000 1101
0000 0000 0100 0000 0110 0100 0000 0000 0000 1110
0000 0000 1000 0000 0111 1000 0000 0000 0000 1111
■
Specification of nL and length of result
Value of nL Effective bit length for
conversion
Value of nL Effective bit length for
conversion
1 2 5 32 (2 byte)
2 4 6 64 (4 byte)
3 8 (1 byte) 7 128 (8 byte)
4 16 (1 byte) 8 256 (16 byte)
7.9 ENCO (Encoding)
WUME-FP7CPUPGR-12 7-21
