[S]...DT1 [n]...U10 [D]...DT10
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the specification for the bit position [n] is not in the following range: 0 ≤ n ≤
15.
To be set if, when the conversion result is stored in the device address specified by [D], it
exceeds the area.
7.16 COLM (Conversion: Bit Line → Bit Column)
