Panasonic FP7 Series - Page 47

Name
Operatio
n
Unit
Mnemonic Operand Function overview
Page
process is performed when the scan is
finished.
■
Special Instruction (When Using FP7 Multi-Wire Link Unit)
Name
Operatio
n
Unit
Mnemonic Operand Function overview
Page
Error Clear
(When Using
FP7 Multi-Wire
Link Unit)
US ERR (P) N
Clears internal errors for the FP7 multi-wire
link unit. Resets the values for the system
relay and system data register.
"P.16-27"
■
Ethernet Communication Instruction (Setting)
Name
Operatio
n
Unit
Mnemonic Operand Function overview
Page
ET-LAN Status
Read
− RDET (P) D
Reads the status for all connections to the
LAN port (ET-LAN) of the unit, and stores it
in [D].
"P.17-3"
(Note 1)
Information
Acquisition of
Ethernet Unit
(IP/MAC
Destination)
− ETSTAT (P)
S1, S2,
D
Stores the unit information (IP/MAC
connection destination) specified by [S1]
and [S2] in the area starting with [D].
"P.17-5"
(Note 1)
Information
Acquisition of
Ethernet Unit
(FTP/HTTP/
SMTP)
− ETSTAT (P)
S1, S2,
D
Stores the unit information (FTP/HTTP/
SMTP) specified by [S1] and [S2] in the
area starting with [D].
"P.17-15"
(Note 1)
IP Address
Setting
− IPv4SET (P) S
Sets the IP address with the setting
parameters stored in the device address
starting with [S] or the number of character
constants. The subnet mask and default
gateway can be omitted.
"P.17-23"
(Note 1)
PING request − pPINGREQ S, D
In order to acknowledge the operations of
communication relay devices, a PING send
request is performed [S] number of times
with the devices indicated in [D].
"P.17-28"
(Note 1)
User
Connection
Setting
− CONSET (P)
S1, S2,
D1, D2
Sets the connection setting parameters
specified by [S1] and [S2] to the range of
[D1] to [D2].
"P.17-32"
(Note 1)
Connection
open
− OPEN (P) S
Opens the connection number specified by
[S].
"P.17-39"
(Note 1)
Connection
close
− CLOSE (P) S
Closes the connection number specified by
[S].
"P.17-41"
(Note 1)
NTP
destination
server settings
− NTPcSV (P) S1, S2
Sets the SNTP server address and time
zone to the CPU unit with a built-in ET-
LAN.
"P.17-43"
(Note 1)
1.2 List of High-level Instructions
WUME-FP7CPUPGR-12 1-29
