Example 6) Unsigned 32 bits (UL) (negative value)
[S]…DT10 [D]…DT0
SF -1.357000E＋02
[i]…UL
DT10・DT11
DT12・DT13
DT14・DT15
U 0
U 0
DT0・DT1
DT2・DT3
DT4・DT5
* Operation error occurs if an unsigned integer is specified for the operation unit and
a negative value is converted.
SF 2.468000E＋02
SF 1.234567E
＋＋
05
Example 7) Signed 32 bits (SL) (positive value)
[S]…DT10 [D]…DT20
SF 1.357000E＋02
[i]…SL
DT10・DT11
DT12・DT13
DT14・DT15
K 0
K 0
DT20・DT21
DT22・DT23
DT24・DT25
K -12345
SF -2.468000E＋02
SF -1.234567E
＋＋
05
Example 8) Signed 32 bits (SL) (negative value)
[S]…DT10 [D]…DT20
SF -1.357000E＋02
[i]…SL
DT10・DT11
DT12・DT13
DT14・DT15
K 0
K 0
DT20・DT21
DT22・DT23
DT24・DT25
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when a non-real number is specified for [S].
To be set when an out-of-range value is specified for [S] (conversion target data).
11.30 FIX (Conversion: Floating Point Real Number Data → Integer (Round
Decimal Digits))
