Panasonic FP7 Series Command Reference Manual

Operation unit Minimum value Maximum value
US 0.00 65535.49
SS -32768.49 32767.49
UL 0.00 4294967295.49
SL -2147483648.49 2147483647.49
■
Processing
Example 1) Unsigned 16 bits (US) (positive value)
[S]…DT10 [D]…DT0
[i]…US
DT0
DT1
DT2
DT10・DT11
DT12・DT13
DT14・DT15
* Operation error occurs if an unsigned integer is specified for the operation unit and
a negative value is converted.
Example 2) Unsigned 16 bits (US) (negative value)
[S]…DT10 [D]…DT0
[i]…US
DT0
DT1
DT2
DT10・DT11
DT12・DT13
DT14・DT15
Example 3) Coded 16 bits (SS) (positive value)
[S]…DT10 [D]…DT0
[i]…SS
DT0
DT1
DT2
DT10・DT11
DT12・DT13
DT14・DT15
Example 4) Coded 16 bits (SS) (negative value)
[S]…DT10 [D]…DT0
[i]…SS
DT10・DT11
DT12・DT13
DT14・DT15
DT0
DT1
DT2
Example 5) Unsigned 32 bits (UL) (positive value)
[S]…DT10 [D]…DT0
[i]…UL
DT10・DT11
DT12・DT13
DT14・DT15
DT0・DT1
DT2・DT3
DT4・DT5
U 235
U 0
U 0
U 0
U 0
SF 2.345670E＋＋02
SF 3.456780E＋02
SF 4.567890E＋02
K 235
K 0
K 0
K -235
K 0
K 0
U 123457
U 0
U 0
SF -2.345670E＋＋02
SF -3.456780E＋02
SF -4.567890E＋02
SF 2.345670E＋＋02
SF 3.456780E＋02
SF 4.567890E＋02
SF -2.345670E＋＋02
SF -3.456780E＋02
SF -4.567890E＋02
SF 1.234567E＋＋05
SF 2.468000E＋02
SF 1.357000E＋02
U 0
11.32 ROFF (Conversion: Floating Point Real Number Data → Integer (Round
to the Nearest Unit))
