Name

Unit memory number (HEX)

Axis 1 Axis 2 Axis 3 Axis 4 Virtual axis

Warning code annunciation

buffer 4

UM001C8

UM001C9

UM001D8

UM001D9

UM001E8

UM001E9

UM001F8

UM001F9

UM00238

UM00239

Warning code annunciation

buffer 5

UM001CA

UM001CB

UM001DA

UM001DB

UM001EA

UM001EB

UM001FA

UM001FB

UM0023A

UM0023B

Warning code annunciation

buffer 6

UM001CC

UM001CD

UM001DC

UM001DD

UM001EC

UM001ED

UM001FC

UM001FD

UM0023C

UM0023D

Warning code annunciation

buffer 7

UM001CE

UM001CF

UM001DE

UM001DF

UM001EE

UM001EF

UM001FE

UM001FF

UM0023E

UM0023F

13.14 PERRD (Acquiring Error/Warning in the Positioning Unit)

WUME-FP7CPUPGR-12 13-25
