Panasonic FP7 Series Command Reference Manual

Control
charact
er
string
Format of data for conversion
Available
operation
units
Data range
ASCII data before
conversion
BIN data after conversion
Floating point real
number (including
exponential notation)
ASCII data
64-bit double-precision
floating point real number
data
DF
1.797693134862231E+308
to 2.2250738585072014E-308
-2.2250738585072014E-308
to -1.797693134862231E+308
(Note 1) For "n", specify the number of digits. Conversion is performed for every "n" digits. However, data
separation occurs wherever a comma (",") appears.
(Note 2) When omitting "n", insert a comma (",") to separate the data.
(Note 3) When there is a comma followed by another comma, it is converted to the value "0". Example: When
the number of the data is three, ",," is processed as the data "0, 0, and 0".
■
Specification of conversion method [N]
Conversion method [N] should be specified in a Hex format (8 digits) in the 32-bit area.
H 01002
H1 to H FFFF (1 to 65535)
Amount of data to be converted
Conversion starting position
Specify the header of the character string to convert from the
relative position of the low byte of [S2]. The round numbers
in the following diagram indicate the relative position.
The character string to be converted starts from relative
position ① for H00 and from relative position ② for H1.
H00: Forward direction
H01: Reverse direction
Conversion direction
H0 to H FF (Conversion)
Specify a conversion direction. Forward direction can only be
specified for hexadecimal data (control string %x) or BCD data
(control string %b). For all other data formats, reverse direction
is specified (fixed).
[D]
H 1234
[S2]
[S2+1]
Forward direction
[S2]
[S2+1]
Reverse direction
4 3
2 1
(Characters)
H34
H32
H33
H31
H32
H34
H31
H33
2 1
4 3
(Characters)
②
④
①
③
⑥ ⑤
[S2]
[S2+1]
[S2+2]
⑧ ⑦
[S2+3]
H L
[N] =
Convert the data to hexadecimal and
specify it here
■
Conversion example
Example 1) Converting two hexadecimal ASCII data (4 digits) to two 16-bit binary
data (hexadecimal)
The conversion starts from the low byte of DT0. It is converted in reverse direction (the low
word side of [S2] is considered as high-order numerical data).
14.11 ATOB (Conversion: ASCII → BIN)
14-48 WUME-FP7CPUPGR-12
