Available bit devices (●: Available)
Operand
Bit device
Specification of bit of
word device
Index
modifier
X Y R L T C P E SR IN OT DT.n LD.n
S1
S2
(Note 1)
● ● ●
(Not
e 2)
(Note 3) (Note 3)
●
n
D1 ● ● ● ● ● ● ●
D2
(Note 1) When the sender is FP7, only global devices can be specified. (A local device cannot be specified.)
(Note 2) In the case of MODBUS mode, a bit device cannot be specified.
(Note 3) In the case of MEWTOCOL-COM mode or MODBUS mode, a bit device cannot be specified.
■
Outline of operation
● Commands are sent from the communication port of the unit to perform the data
transmission with external devices.
● Data can be read and written by specifying station numbers and memory addresses and
executing the SEND and RECV instructions in a user program, because PLC automatically
creates messages according to the protocol.
● Select a communication mode in the configuration menu of the tool software FPWIN
GR7.
● When the RECV instruction is executed, the data is read from the address that starts with
[S2] in the partner station number [S1] and the data is stored in the area that starts with [D1]
in the master unit.
● Depending on the type of device specified by [S2] and [D1], the transfer method (register
transfer / bit transfer) varies.
● The amount of received data [n] is specified in words for the register transfer, and in the
number of bits for the bit transfer.
● The execution result code is stored in the one-word area of the master unit that is specified
by [D2].
■
Specification of partner unit station number [S1]
Communication Mode When SCU is used When ET-LAN is used
MEWTOCOL-COM 1 to 99, 238 (decimal) = EE
(hexadecimal)
1 to 64, 238 (decimal) = EE
(hexadecimal)
(Note 1)
MEWTOCOL-DAT
(Note 1)
Non-SCU-compliant
MODBUS 1 to 255 1 to 255
(Note 1) For connection between FP7 and FP7, specify "1". Destination is determined by the IP address.
■
Specify the starting address [S2] of the sender data area
Transfer method Communication Mode Address range
Register transfer
MEWTOCOL-COM 0 to 99999
15.5 RECV (MEWTOCOL Master / MODBUS Master)
15-30 WUME-FP7CPUPGR-12
