[S] value Type of acquired data Number of stored data
0 Communication parameter 26 word
1 Communication monitoring area information 7 word
2 PLC link status flag information 8 word
3 PLC link error frequency information 9 word
4 PLC link time interval information 8 word
5 PLC link settings parameter monitoring information 192 word
■
Acquired data (communication parameters): When [S] = 0
Storage
location
Items Range: Description
[D] Communication Mode
H0
U1
U2
U8
U9
U0: MEWTOCOL-COM
U1: MEWTOCOL7-COM
U2: MODBUS-RTU
U8: General-purpose Communication
U9: PLC link
[D+1] Station number setting
U1 to
U999
Station number U1 to U999
MEWTOCOL-COM: U1 to U99
MEWTOCOL7-COM: U1 to U999
MODBUS-RTU: U1 to U247
PLC link: U1 to U16 (Default: 0)
[D+2] Baud rate setting U0 to U10
U0: 300, U1: 600, U2: 1200, U3: 2400, U4: 4800, U5: 9600,
U6: 19200, U7: 38400, U8: 57600, U9: 115200, U10:
230400 bps
[D+3] Data length setting U0, U1 U0: 7-bit length, U1: 8-bit length
[D+4] Parity setting U0 to U2
U0: No parity, U1: Odd parity, U2: Even parity, U3: Parity
fixed to 0
[D+5] Stop bit length setting U0, U1 U0: 1 bit, U1: 2 bits
[D+6]
RS/CS enabled or
disabled
(Note 1)
U0, U1 U0: Disable, U1: Enable
[D+7] Send waiting time
U0 to
10000
U0: Immediate Effective time = Un x 0.01 ms (0 to 100 ms)
[D+8] Start code STX U0, U1 U0: Disable, U1: Enable
[D+9] Terminator setting U0 to U3 U0: CR, U1: CR+LF, U2: Time, U3: ETX
[D+10]
Terminator judgement
time
U0 to
U10000
U0: 32 bits
Effective time = Un × 0.01 ms (Only enabled when the end
setting is "Time".)
[D+11] Modem initialization U0 to U2
U0: Not initialize
U1: Execute the first initialization only
(Note 2)
U2: Re-execute initialization at the time of setting.
[D+12] to
[D+13]
Reserved for system H0 Reserved area for system
[D+14] Link area block number U0, U1 Block number of link relay/link register area
15.9 PMGET (Acquiring SCU Parameters)
WUME-FP7CPUPGR-12 15-59
