Storage
location
Items Range: Description
[D+15]
PLC link W0 maximum
station number
U2 to U16 Values out of the range are handled as "16".
[D+16] Range of link relays U0 to U64
Specify the range of link relays used for communication
(specification by number of words, relative values within the
specified block)
[D+17] Range of link registers
U0 to
U128
Specify the range of link registers used for communication
(relative values within the specified block)
[D+18]
Link relay sending start
number
U0 to U63
Link relay sending start number (specification by number of
words, relative value within the specified block)
[D+19]
Size of link relay send
area
U0 to U64
Size of link relay send area (specification by number of
words)
[D+20]
Link register sending
start number
U0 to
U127
Link register sending start number (specification by number
of words, relative value within the specified block)
[D+21]
Size of link register send
area
U0 to
U127
Size of link register send area (specification by number of
words)
[D+22] to
[D+25]
Reserved for system H0 Reserved area for system
(Note 1) RS/CS can be selected only when an RS-232C (5-wire) x 1-channel communication cassette (product
number AFP7CCS2) is used.
(Note 2) The modem is initialized at the time of setting (when the power is on, PMGET instruction is executed,
or switching to the RUN mode). Initialization is executed only in the first session. (Excluding when the
power supply is turned off and then on again.)
(Note 3) Settings of [D+14] to [D+21] are only enabled when the communication mode of the COM1 port is PLC
link.
■
Acquired data (communication monitoring area information): When [S] = 1
Storage
location
Items Range: Description
[D] Operation mode
U 0
U 1
U 2
U 8
U 9
HFFFF
U0: MEWTOCOL-COM
U1: MEWTOCOL7-COM
U2: MODBUS-RTU
U8: General-purpose Communication
U9: PLC link
HFFFF: Modem initialization
[D+1]
Communication
cassette detection
H0
U232
U422
U485
U0: No communication cassette
U 232: RS-232C
U 422: RS-422
U 485: RS-485
[D+2]
Reception error
code
-
The bits corresponding to when an error occurs turn ON. (0:
Normal, 1: Error)
Bit 0: Receive buffer overrun
Bit 1: Stop bit undetected (frame error)
Bit 2: Parity inconsistency
Bit 7 to 3: 0 (fixed)
Bit 8: Receive buffer overflow
Bit 9: Receive buffer FULL
15.9 PMGET (Acquiring SCU Parameters)
