● For FP7 multi-wire link unit, only one of those instructions can be executed for one unit at a
time.
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the source range is outside the accessible range.
To be set when the FP7 multi-wire link unit that is specified by UNITSEL does not exist.
To be set when the data device specified by [S] is incorrect or exceeds the area.
To be set when the amount of sent data specified by [n] is incorrect.
To be set when the station number that is specified by [D1] is out of the range.
To be set when the data device specified by [D2] is incorrect or exceeds the area.
To be set when the result storing device that is specified by [D3] is incorrect.
To be set when the type (1-bit or 16-bit) of the specified device is different between [S] and
[D2].
16.1 SEND (When FP7 Multi-wire Link Unit Is Used)
WUME-FP7CPUPGR-12 16-5
