Panasonic FP7 Series Command Reference Manual

[S] value Type of acquired data
Number of stored
data
Storage location
0 PLC link communication state 3 word [D] to [D+2]
1 Network participation state 3 word [D] to [D+2]
2 W link communication error information 15 word [D] to [D+14]
3
PLC link refresh operation monitoring
information
8 word
[D] to [D+7]
■
Acquired data (PLC link communication state): When [S] = 0
Storage
location
Items Range: Description
[D]
PLC link address
duplicate station number
H0 to HF
Bit 0 to bit 15: Unit number 1 to unit number 16
OFF: Normal
ON: Area duplication occurs (The position of the partner unit
is set to ON)
[D+1]
PLC link transmission
assurance relays
Bit 0 to bit 15: Unit number 1 to unit number 16
OFF: When stopped or in abnormal state
ON: PLC link communicating normally
[D+2]
PLC link operation
mode relay
Bit 0 to bit 15: Unit number 1 to unit number 16
OFF: PROG mode
ON: RUN mode
■
Acquired data (network participation state): When [S] = 1
Storage
location
Items Range: Description
[D]
Number of units added
to the link
U0 to U32
The number of units added to the link is stored. The value is
0 when the existing unit in the network is only one or a
station number is being changed.
[D+1]
Link participation unit
flag
Unit nos. 1 to 16
H0 to HF
Bit 0 to bit 15: Unit number 1 to unit number 16
OFF: Not exist
ON: Participating
[D+2]
Link participation unit
flag
Unit nos. 17 to 32
Bit 0 to bit 15: Unit number 17 to unit number 32
OFF: Not exist
ON: Participating
■
Acquired data (W link communication error information): When [S] = 2
Storag
e
locatio
n
Items Range: Description
[D]
Number of occurrences of non-token
state
U0 to U255
The number of occurrences of each error
is stored.
[D+1]
Number of occurrences of duplicate
tokens
[D+2]
Number of occurrences of non-signal
state
16.3 PMGET (Acquiring MEWNET-W Parameters)
WUME-FP7CPUPGR-12 16-11
